Specifications

4K UHD / 25P
MP4 up to 150Mbps

20x optical zoom
29.3 – 601mmWide-angle 4K zoom

Over Sampling HD Processing
High quality Full HDUses the 4K UHD sensor to deliver superior Full HD images

Optical IS
5-Axis ISAdvanced optical and dynamic image stabilisation

Touch Screen
3.5-inch touch screenEasy focus point and camera control

Audio
Stereo electret condenser mic plus 3.5mm external mini jack

Double slot
Dual card slotsSD card simultaneous or relay recording

USB-C
Video livestream output via Mac or PC1 Also compatible with Canon’s GP-E2 GPS receiver

Specifications in detail
Image Sensor

Sensor

1/2.3-type CMOS

Filter

RGB Primary Colour Filter

Total Pixels

Approx. 21.14MP

Effective Pixels per Sensor

Approx. 8.29 MP (3840 x 2160)

Subject Illumination Range

Approx. 0.3 lx to 100,000 lx

Minimum Illumination (PAL)

P (Program AE) Mode:  Approx. 4.2 lx (shutter speed 1/25 sec with auto slow shutter On)Low Light Mode: Approx. 0.3 lx (shutter speed 1/2 sec.)

Image Processor

Type

DIGIC DV 6

Colour Sampling

YCC 4:2:0 8bit

Lens

Zoom Ratio

20x Optical

Focal Length (35mm Equivalent)

Approx. 29.3 – 601mm Standard IS/IS Off

Minimum Focus Distance

1 cm at wide end, 60 cm across entire zooming range

Max. Aperture

f/1.8 – 2.8 (AV Priority and Manual Modes)

Aperture Blades

8 blades

Filter Diameter

58mm

Image Stabilization System

Optical system (lens shift) + electronic stabilizationDynamic, Standard, Powered IS, Off

ND Filter

Built-in gradation filter (Auto or Off)

Zoom Control

Zoom rockers on body and handle;Selectable manual zoom/focus ring on lens;Selectable High Speed and Soft Zoom modes available.

Zoom Speed

Variable (body rocker only) or Constant speed (body and handle rocker; Fast/Normal/Slow, 16 speed level settings in each)

Focus Control

MANUAL:  Lens ring and touchscreen point selection (Magnify and Peaking assist functions), Focus Preset.AUTOFOCUS:  Touchscreen AF point selection, Face Detection and Tracking, Touch and Track, Face Only AF.(Instant AF, Medium AF, Normal AF)

Focus System

Hybrid AF (High Speed/Medium speed). Uses combination of TTL-video signal detection system and external phase difference metering system. Normal AF. TTL, Contrast based AF

Iris Control

Touchscreen, Auto

Digital Zoom/Teleconverter

20x digital zoom (400x with optical zoom) and 40x digital zoom (800x with optical zoom) are available. Digital zoom not available in AUTO mode.2x Digital Teleconverter

Recording

Video Storage Media

SD/SDHC/SDXC card (2 card slots)

Recording Time

150Mbps: 55 mins / 35Mbps: 240 mins / 17Mbps: 495 mins

Recording File System

FAT32/exFAT

Internal Recording Format (PAL)

MP4:3840 x 2160 / 25.00P(150 Mbps)1920 x 1080 / 50.00P, 25.00P (35, 17 Mbps)

External Recording Output

HDMI output (When Shooting):UHD recording mode:1920 x 1080 / 25.00P, 50.00P (for Slow&Fast), 50.00i (PsF mode); 1280 x 720 / 50.00P YCC 4:2:2 8-bitFull HD recording mode:1920 x 1080  50.00P/25.00P/50i ; 1280 x720 50.00P YCC4:2:2 10-bit

Slow/Fast Motion (PAL)

3840 x 2160 / 25.00P:  x2, x4, x10, x20, x60, x120, x600, x12001920 x 1080 / 50.00P:  x2, x4, x10, x20, x60, x120, x600, x12001920 x 1080 / 25.00P:  x0.5

Pre-Record Function

Yes. 3 seconds

Still Photos

JPEG up to 3840×2160(Still image resolution is dependent on the video resolution)

Photo Storage Media

SD Card

System

Display Type

Capacitive LCD touch panel

Size

3.5-inch (8.8 cm) on the diagonal, Approx. 2,760,000 dots (1280 x RGB x 720)

Wave Form Monitor

No

Focus Assist

Peaking / Magnify

Peaking

Selectable Peaking Colour: Red / Blue / Yellow

Zebra

70% or 100% reference level

Markers

Grid (white/grey), Level (white/grey), 4:3 (white/grey)

EVF

Size

0.36-inch (0.92 cm on the diagonal), Approx. 1,770,000 dots (1024 x RGB x 576)

Correction Lens

+2.0 to -5.5 dioptre

Inputs / Outputs

Audio Input

3.5mm microphone input jack (Supply Voltage 2.4V DC) Built-in Mic

Headphone Output

3.5mm stereo mini jack

HDMI Output

HDMITM mini connector

USB

Type-CHi-Speed USB (USB 2.0) equivalent.Point-to-point class and UVC supported.

SDI Output

NA

Time Code

No

Genlock

No

LAN

No

AV Terminal

No

DC Input

USB-C

Remote Control Terminal

2.5mm mini jack

Miscellaneous

Tally Lamp

NA

Colour Bars (PAL)

Yes. SMPTE, ARIB or EBU, with 1KHz Tone

Accessory Shoe

Yes (cold shoe)

Assignable Buttons

5 assignable Buttons

Custom Dial

Iris/Shutter/Gain, AGC Limit, Exposure Compensation, Off

Exposure

Exposure Metering

Center-weighted average meteringAUTO, P, Av, Tv, Portrait, Sports, Low Light and IR modesSegment evaluative meteringNight Scene, Snow, Beach, Sunset, Spotlight modesNo metering in Fireworks mode: Exposure constant

Exposure Compensation

Highlight AE, Normal, Exposure lock, Auto backlight compensation.

Exposure Lock

Yes.

Auto ISO / Auto Gain Control Setting

Auto / Manual

Auto Gain Control Limit

0 – 23dB (1dB increments)

Shutter Speed

Control Modes

Auto, P, Tv, Manual

Shutter Speed (PAL)

1/6 – 1/2000 sec(1/2 – 1/500 sec in Low Light mode)

Slow Shutter (SLS)

50.00P:Auto slow shutter On: 1/25 to 1/500 sec.Auto slow shutter Off: 1/50 to 1/500 sec.25.00P:Auto slow shutter On: 1/12.5* to 1/500 sec. (*Display is 1/12)Auto slow shutter Off: 1/25 to 1/500 sec.

Clear Scan (PAL)

No

Streaming, Wi-Fi, & GPS Specifications

IP Streaming Protocols Supported

UVC via USB-C (Audio output not supported via USB-C)

Wi-Fi

No

GPS Information (Optional Accessory)

Location (Latitude/Longitude/Altitude), Coordinated Universal Time (UTC), Satellite reception.(requires the optional GPS Receiver GP-E2)

White Balance

Auto

Yes

Preset

Daylight (Approx. 5,600K), Tungsten (Approx. 3,200K)

Manual Setting

Colour Temperature range: 2,000–15,000KDefault value for Set 1 and Set 2:  5,600K

Shooting Modes

Custom Picture Menu

C1: Normal (BT.709 Normal / BT.709)C2 to C6: USER02 to USER06

Look Settings

Standard(Adjustment:  Sharpness, Contrast, Colour Depth)

Colour Matrix Settings

Neutral: accurate colour reproductionVideo: Higher contrast colour reproduction

Infrared Shooting Mode

Not supported

Audio

Recording Format

MPEG-2 AAC-LC (16-bit 2ch) / LPCM (16-bit 4ch)

Audio Control

Manual/AutoIndependent 2ch Line/Mic/Mic+48V input;Independent level control per channel (-∞ to +18 dB);Independent audio limiters (2 ch);Input mic trimming

Reference Tone

1KHz, -12dB / -18dB / -20dB / Off

Microphone Attenuation

On/Off (20dB)

Microphone Level Meter

Yes

Accessories

Supplied

Lens hood with barrier, Battery Pack BP-820, USB Power Adapter PD-E1, AC Cable

Optionals

Canon Battery Pack BP-820/BP-828, Canon Battery Charger CG-800E/CG-800, Canon HDMI cable HTC-100/HTC-100S, Canon Tele Converter TL-H58, Canon Wide Attachment WA-H58, Canon Shoulder Strap SS-600/SS-650, Wrist Strap WS-20, Canon PROTECT Filter 58mm, Canon ND4-L Filter 58mm, Canon ND8-L Filter 58mm, Canon GPS Receiver GP-E2, Canon Remote Controller RC-V100, Canon Battery Video Light VL-10Li/VL-10LiII, Canon Battery Pack BP-900 series (for VL-10Li/VL-10LiII), Canon Compact Power Adapter CA-910/920/930 (for charging BP-900 series), Canon Interface Cable IFC-300PCU/S / IFC-400PCU

Power Source

Power Supply (Battery)

Canon Battery Pack BP-820 (supplied), BP-828 (optional)

Power Consumption

UHD:MP4, 150Mbps 25.00P :  Approx. 4.5WFull HD:MP4, 35Mbps 50.00P : Approx. 4.6W

Recording Time

UHDMP4: 150Mbps/25.00p: Max. 165 mins (BP-820), typical 95 mins /Max. 240 Mins, typical 140 mins ( Optional BP-828)

Physical Specifications

Dimensions

Approx. 109 x 84 x 182 mm

Weight (Body Only)

Approx. 740g

Weight (Accessories)

NA

Operating Temperature Range

0ºC to +40ºC, 85% relative humidity
